Certifications and Patents

PATENTS AND CERTIFICATES

Every new Cabel System product is tested systematically by CESI, until its function and performance is completely guaranteed. For example, circuit examination is performed through a series of brief tests without breakers, shorting directly the main busbars. The test is the most extreme required by law – the system is placed under stress of short circuit for 1 full second, without any breaker to protect it.

Cabel System, while developing its products over the years, has successfully passed the following tests:

Test Report MP-95/000687
Short-circuit test for 1 second on a busbar system consisting of slanted busbars with In=630 A, Icc 16 kA / 32 pkA
Test Report MP-95/000470
Short-circuit test for 1 second on a busbar system consisting of parallel busbars with In=3200 A, Icc 60 kA / 132 pkA
Test Report MP-95/032466
Short-circuit test for 1 second on a busbar system consisting of parallel busbars with In=5000 A, Icc 100 kA / 220 pkA.
Test Report MP-97/029210
Short-circuit test for 1 second on a HERGO busbar system with In=6300 A, Icc 150 kA / 330 pkA.

CERTIFICATIONS

The latest certifications are:

Temperature Rise Test with ASTA DESLARATION TEST ref. n° AST-51-59 to standard CEI EN 61439-1
Impulse Withstand Voltage Test ASTA DECLARATION TEST with report n° AST-51-59 to standard CEI EN 61439-1;
Defgrees of protection provided by enclosures IP31 with report DEKRA n° 3502618.50 to standard EN 60529
Defgrees of protection provided by enclosures IP42 with report DEKRA n° 3502618.60 to standard EN 60529
Defgrees of protection provided by enclosures IP54 with report DEKRA n° 3503914.50 to standard EN 60529
Defgrees of protection provided by enclosures for electrical equipment against external mechanical impacts with report DEKRA n° 3502618.70 to standard EN 62262
Corrosion test with attestation of conformity DEKRA n° 350261800 to standard IEC 60068-2-30
Salt mist test with report DEKRA n° 350361600 to standard IEC 60068-2-11

To ensure operator safety, we have also performed — and successfully completed — an internal arc fault test (the first test of its kind in Europe) at CESI, the Italian Experimental Electro-technical Centre.

Test Report A6/007691
Short-circuit test under conditions of arcing due to an internal fault on a switchboard with In=7100 A, Icc 50 kA and admissible arcing time of 0.3"
Test Report A6/007693
Short-circuit test under conditions of arcing due to an internal fault on a switchboard with In=7100 A, Icc 100 kA and admissible arcing time of 0.3"

PATENTS

Cabel System boasts the first European test report (MP-97/029210, In=6300 A, Icc 150 kA/330 pkA) on the HERGO busbar system, currently produced in our laboratories, unique of its kind and protected by International Patent No 98 118 419.5-220.
